Circular Tumbler Screen

The design of the circular tumbler screen is a high-efficiency screening machine specially designed to meet the needs of large-volume, higher-screening manufacturers. The simplest screening is to use both eyes to screen with both hands. Simulation, it is currently the most effective simulation of the effective principle of manual screening movement (screening accuracy, efficiency, screen life is 5-10 times that of conventional round screen), which meets all fine and ultra-fine powders and particles Shaped materials, especially suitable for difficult materials.

Quantity:
  • YBS

Description of circular tumbler screen:

The design of the circular tumbler screen is a high-efficiency screening machine specially designed to meet the needs of large-volume, higher-screening manufacturers. The simplest screening is to use both eyes to screen with both hands. Simulation, it is currently the most effective simulation of the effective principle of manual screening movement (screening accuracy, efficiency, screen life is 5-10 times that of conventional round screen), which meets all fine and ultra-fine powders and particles Shaped materials, especially suitable for difficult materials.

微信图片_20200718093847

Technical parameters of circular tumbler screen:

Model

Availability   of screening area

(m*m)

Screen slope   (angel)

Grain   size(mm)

Double   amplitude

(mm)

Power

(kw)

Process   capacity(t/h)

YBS -1000

0.71

0-10

10

5-8

1.5

8-15

YBS -1200

1.11

5-8

2.2

15-30

YBS -1600

1.83

5-8

2.2/4

25-50

YBS -2000

2.62

5-8

2.2/4

30-60

YBS -2200

3.46


3/4

35-60

YBS -2600

5.31

5-8

5.5

45-60

Notes:The parameter above is just for reference.More models pls inquiry us directly.

Working principle of circular tumbler screen:

The YBS series tumbler screen is a low-frequency vibrating screen that imitates artificial vibration. The principle is that the instantaneous motion is the synthesis of the circular motion along the radial displacement and the displacement as the axis. Can regulate the vibrator eccentricity produce nonlinear three-dimensional movement, material also can produce the same approximation manual operation movement, so as to achieve the aim of screening, coupled with sieving attachment can get more ideal screening effect.

Suitable for round ball, cylindrical, flaky, even irregular shape easy to be blocked and need precise screening materials.

微信图片_20200718093910

微信图片_20200718093921

Features of circular tumbler screen:

YBS type circular tumbler screen sieve uses ranges of professional designs to reach customers’ extremely demand:



1. Cleaning system with balls, air, ultrasonic is equipped to prevent blinding and maintain easily.

2. Grading up to 6 particle sizes, achieving 99% separating accuracy.

3. Reasonable acceleration, long-lasting parts, reduced maintenance.

4. Less 75 decibels noisy, the optimized balance of balance, low dynamic load on the foundation

微信图片_20200718093932

Applicable industry of circular tumbler screen:

Food industry: sugar, spices, starch, soybeans, salt, instant potatoes, animal feed, powdered milk, cereals and grains, tobacco, teff, instant coffee granules, chocolate powder, soybean flour, broth concentrate, potato granules, sugar beets, ice cream, fruit juices, vegetable and pickle canneries, soybean oil.

Construction Industry: sand, glass beads, plaster, abrasives Grit/shot, borax.

Chemical Industry: fertilizer, rubber, polystyrene beads, paint, detergents, latex, catalyst, casein.

Recycle: animal blood, paper effluent, brewer yeast, sewage, manure, brewery waste, laundry waste, potato peelings and waste, tallow.

微信图片_20200718093947

Cleaning system of circular tumbler screen:

微信图片_20200718094002

Product display:

 1 (1)

1-(4)


1 (5)

1 (6)

1 (7)

1 (9)

Customer site:

客户现场拼图
